Power over Ethernet

802.3af

Frequency range [MHz]

2412 - 2472, 5180 - 5825

Operating mode

Access Point

Wireless frequency

2.4 + 5 GHz (dual band)

WiFi standards

802.11a, 802.11ac, 802.11ac - wave2, 802.11ax, 802.11b/g, 802.11n

MU-MIMO

Yes

Transmission speed - 2.4GHz [Mb/s]

574

Transmission speed - 5GHz [Mb/s]

2402

Tx power 2.4GHz [dBm]

23

Tx power 5GHz [dBm]

23

Security

WEP, WPA, WPA2, WPA3

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

Type of antenna

Built-in

Internal antennas

4

Purpose

Indoor

Antenna gain [dBi]

2, 3

LAN ports

2

LAN speed

(2) 10/100/1000Mbps

Gigabit LAN

Yes

PoE type

PoE-In (only)

Max. power consumption [W]

12

USB ports 2.0

1

Power via connector/terminal

12V DC

Operating temperature [°C]

0 up to 40

Weight [g]

320

Depth [mm]

160

Width [mm]

86

Height [mm]

38

CPU

Dual Core

CPU frequency [MHz]

1000

USB

Yes

RAM [MB]

512
