Power over Ethernet

802.3af, 802.3at

Operating mode

Access Point

Wireless frequency

2.4 + 5 GHz (dual band)

WiFi standards

802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ac - wave2, 802.11ax, 802.11be

MU-MIMO

Yes

Transmission speed - 5GHz [Mb/s]

2880

Transmission speed - 2.4GHz [Mb/s]

688

Tx power 2.4GHz [dBm]

23

Tx power 5GHz [dBm]

23

Security

WPA3 AES

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

Type of antenna

Built-in

Purpose

Indoor

Antenna gain [dBi]

4, 5

LAN ports

1

LAN speed

(1) 100/1000/2500Mbps

Gigabit LAN

Yes

Max. power consumption [W]

13,5

Power via connector/terminal

12V DC

Buttons

Reset

Operating temperature [°C]

-10 up to 50

Weight [g]

470

Width [mm]

180

Height [mm]

35

Depth [mm]

180

USB

Yes
