Teltonika TRM500 - 5G Modem with USB Type-C
Your price incl. VAT (%)
0.00
❌ The item is not available. There is no option to order.
No confirmed delivery date
You have a choice of 2 variants
Product description
5G MODEM WITH USB TYPE-C
The TRM500 is a compact and lightweight 5G modem with ultra-high cellular speeds of up to 3.4 Gbps. This industrial-grade 5G modem features backward compatibility with 4G (Cat 19) and 3G networks, four SMA antennas for enhanced coverage, DIN rail mounting options, and a USB Type-C interface for simultaneous network data and powering.
Package contents
- Device
- 9 W PSU
- 4 x 5G Mobile antenna (swivel, SMA male)
- 1 x hex key
- SIM Adapter kit
- QSG (Quick Start Guide)
- USB Type-C cable (0.8 m)
- Packaging box
Download
Technical parameters
LAN ports
Interface
USB Type-C
Protection class
IP30
Design
DIN rail, On the wall
Wireless frequency
3G (GSM), 4G (GSM), 5G (GSM), LTE
Purpose
Indoor
Integrated 4G/LTE radio part
Yes
Max. power consumption [W]
12
Chassis design
Metal
Power via connector/terminal
9 .. 30V DC, USB Type-C: 5 VDC (min. 3A)
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
94
Width [mm]
83
Height [mm]
25
Depth [mm]
85
SIM slot
Yes
SIM slots quantity
1
