USB ports 3.0

1

Power over Ethernet

802.3at

Maximum modulation

4096 QAM

Operating mode

Access Point

Wireless frequency

2.4 + 5 + 6 GHz (triple band)

WiFi standards

802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax, 802.11be

MU-MIMO

Yes

Transmission speed - 6GHz [Mb/s]

11520

Transmission speed - 5GHz [Mb/s]

1400

Transmission speed - 2.4GHz [Mb/s]

688

Tx power 2.4GHz [dBm]

23

Tx power 5GHz [dBm]

23

Tx power 6GHz [dBm]

26

Security

WPA, WPA2, WPA3

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

6GHz MIMO

4 x 4

Type of antenna

Built-in

Purpose

Indoor

Roaming

Yes

Antenna gain [dBi]

4, 5

LAN ports

2

LAN speed

(1) 100M/1/2.5/5G + (1) 10/100/1000M

Gigabit LAN

Yes

Max. power consumption [W]

21

Power via connector/terminal

12V DC

Buttons

Reset

Operating temperature [°C]

-10 up to 50

Weight [g]

745

Height [mm]

45

Depth [mm]

220

Width [mm]

220

USB

Yes

Default IP address

Dynamic from DHCP

Default login and password

Is set by the user at the first startup
