MikroTik RouterBOARD RBSXTsq2nD, SXTsq Lite2, L3
Your price incl. VAT (%)
0.00
❌ The item is not available. There is no option to order.
No confirmed delivery date
excl. VAT
Product description
The SXTsq Lite2 is a compact and lightweight outdoor wireless device with an integrated antenna. Perfect for point-to-point links or as a CPE unit. It is compact, weatherproof and easy to mount. The SXTsq Lite2 retains a 10 dBi antenna like the SXT Lite2, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.
Variable installation
The enclosure includes slots for directly attaching a hose clamp mount in three different mounting places, with ability to be mounted on horizontal railings. The device includes one 10/100 Mbit Ethernet port. There is also an easily accessilble grounding connection to protect it against lightning.
Package contains
- Device
- Power adapter 24V/0.38A
- PoE injector
- Metal ring
Download
Technical parameters
LAN ports
Power over Ethernet
10 .. 30V DC
Tx power [dBm]
30
Design
Outdoor
Wireless frequency
2.4 GHz
WiFi standards
802.11b/g, 802.11n
Transmission speed - 2.4GHz [Mb/s]
300
2.4GHz MIMO
2 x 2
Type of antenna
Built-in
Antenna gain [dBi]
10
Power type
PoE
Operating system
RouterOS - L3
LAN ports
1
LAN speed
(1) 10/100Mbps
PoE type
PoE-In (only)
Max. power consumption [W]
5
Operating temperature [°C]
-40 up to 70
Width [mm]
129
Height [mm]
129
Depth [mm]
34
CPU
QCA9533
CPU frequency [MHz]
650
CPU cores
1
Default IP address
192.168.88.1
Internal storage [MB]
16
RAM [MB]
64
Default login and password
admin / -
