Teltonika RUTXR1 Enterprise rack-mountable SFP/LTE router
Your price incl. VAT (20.0%)
401.87 EUR
Ordered for stock
Planned Delivery Date by Courier to you 28-01-2026
Product description
RUTXR1 is a rack-mountable LTE Advanced (LTE-A) router equipped with 5x Gigabit Ethernet ports, WiFi, Dual-SIM, USB port, Console port, redundant power supplies, SFP port and RutOS software for advanced networking solutions.
There is the WAN SFP port for optical connection. Additional peripherals or storage can be connected using the USB 2.0 port. The CPU Quad Core ARM Cortex A7 with the clock rate of 717MHz and 256MB DDR3 RAM ensure smooth operation. Power is provided by 12V power adapter. However, it is possible to connect two sources to the device, with the second being intended as a backup in the event of blackout.
Package contents
- Device
- 2 x LTE antennas (magnetic mount, SMA male, 3 m cable)
- 2 x WiFi antennas (magnetic mount, RP-SMA male, 1.5 m cable)
- Rack mounting kit
- SIM Adapter kit
- 18W Euro PSU
- Ethernet cable (1.5 m)
- QSG (Quick Start Guide)
Download
Technical parameters
LAN ports
Design
Desktop, Railmount
Operating mode
Access Point, AP Router, Client, Client Router (wisp), Cellular router
Wireless frequency
2.4 + 5 GHz (dual band), LTE, 4G (GSM), 3G (GSM)
WiFi standards
802.11ac - wave2, 802.11b/g, 802.11n
Transmission speed - 5GHz [Mb/s]
866
Transmission speed - 2.4GHz [Mb/s]
300
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Detachable
Detachable antennas
4
RF connectors
(2) RSMA female, (2) SMA female
Integrated 4G/LTE radio part
Yes
Power type
4-pin automotive
4G/LTE bands support
(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (32) 1500 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
4
LAN speed
(4) 10/100/1000Mbps + (1) 10/100/1000Mbps WAN
SFP cages
1
Optical interfaces
(1) 1000Mbps
Max. power consumption [W]
18
Power via connector/terminal
9 .. 50V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
1093
Width [mm]
272
Height [mm]
43
Depth [mm]
123
CPU
Quad-core ARM Cortex A7
CPU frequency [MHz]
717
SIM slot
Yes
SIM slots quantity
2
USB
Yes
IPv6 support
Yes
Default IP address
192.168.1.1
Internal storage [MB]
256
RAM [MB]
256
Default login and password
admin / (preset password, see label/engraving)
