Grandstream GWN7062M, Dual-Band Wi-Fi 6 router
Your price incl. VAT (20.0%)
90.77 EUR
✅ Availability in an external Partner
Planned Delivery Date by Courier to you 01-07-2026
Product description
Grandstream GWN7062M is a powerful dual-band Wi-Fi 6 router operating simultaneously on the 2.4GHz and 5GHz bands to deliver a maximum throughput of up to 3Gbps. It is equipped with (1) 2.5G SFP/RJ45 combo WAN port, (1) 2.5G LAN port, (3) 1G ports (1x LAN/WAN, 2x LAN) and modern technologies such as VPN, roaming and MU-MIMO. It supports management via a local web interface, GDMS cloud management and GWN Manager.
Key features
- (1) 2.5Gbps SFP/RJ45 combo WAN port, (1) 2.5Gbps LAN port, (3) 1Gbps ports (1x LAN/WAN, 2x LAN), (1) USB 2.0 port
- Total throughput up to 3Gbps - 574Mbps on 2.4GHz (2x2:2) and 2402Mbps on 5GHz (3x3:2)
- Mesh - supports mesh networking with GWN7062M/GWN7062E/GWN7062ET/GWN7660EM
- Multi-WAN with load balancing and failover
- VPN support, including site-to-site VPN
- Powered via 12V DC connector
Package contents
- Device
- Power adapter
- Patch cable
Download
Technical parameters
LAN ports
WAN speed
(1) 2.5G Combo
Max. WAN speed
2.5G
Operating mode
AP Router
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11a, 802.11ac, 802.11ax, 802.11b/g, 802.11n
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
2402
Transmission speed - 2.4GHz [Mb/s]
574
Tx power 2.4GHz [dBm]
24
Tx power 5GHz [dBm]
26
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
3 x 3
Type of antenna
Fixed
Fixed antennas
5
Purpose
Indoor
Antenna gain [dBi]
5
LAN speed
(1) 10/100/1000/2500Mbps + (2) 10/100/1000Mbps + (1) 10/100/1000Mbps LAN/WAN
LAN ports 1G
3
LAN ports 2.5G
2
Gigabit LAN
Yes
SFP cages
1
Optical interfaces
(1) 1G/2.5Gbps
Max. power consumption [W]
18
USB ports 2.0
1
Power via connector/terminal
12V / 1,5A
Buttons
Reset, sync
Operating temperature [°C]
0 up to 45
Weight [g]
400
Width [mm]
205
Height [mm]
36
Depth [mm]
130
CPU
Dual Core
CPU frequency [MHz]
1300
USB
Yes
