Power over Ethernet

9 .. 50V DC

Design

Industry

Operating mode

Cellular router

Wireless frequency

LTE, GNSS, 3G (GSM)

Type of antenna

Detachable

Detachable antennas

3

RF connectors

(3) SMA female

Integrated 4G/LTE radio part

Yes

Power type

PoE, 4-pin automotive

4G/LTE bands support

(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (28) 700 MHz, (32) 1500 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN speed

(4) 10/100/1000Mbps

LAN ports 1G

4

Max. power consumption [W]

9

Power via connector/terminal

9 .. 50V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

455

Width [mm]

115

Height [mm]

44

Depth [mm]

95

CPU

ARM Cortex A7

CPU frequency [MHz]

717

SIM slot

Yes

SIM slots quantity

2

USB

Yes

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

256

RAM [MB]

256

Default login and password

admin / (preset password, see label/engraving)

GPS modul

Yes
