Category
Download
Technical parameters
LAN ports
Power over Ethernet
802.3af, 48V DC
Sensitivity [dBm]
-93
Operating mode
Access Point
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
1300
Transmission speed - 2.4GHz [Mb/s]
450
Tx power 2.4GHz [dBm]
20
Tx power 5GHz [dBm]
28
Security
WEP, WPA, WPA2
2.4GHz MIMO
3 x 3
5GHz MIMO
3 x 3
Type of antenna
Built-in
Internal antennas
6
Purpose
Indoor
Roaming
Yes
Antenna gain [dBi]
4, 3,5
LAN ports
2
LAN speed
(2) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
12,3
Buttons
Reset
Operating temperature [°C]
0 up to 40
Weight [g]
359
Width [mm]
206
Height [mm]
182
Depth [mm]
37
Default IP address
192.168.0.254
Default login and password
admin / admin
