Power over Ethernet

9 .. 30V DC

Protection class

IP30

Design

Industry

Supported VPN

PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE, Tinc

Operating mode

Client, AP Router, Access Point, Cellular router

Management

Web management, SSH, Teltonika RMS

Wireless frequency

2.4 + 5 GHz (dual band), LTE, 3G (GSM), 4G (GSM), 5G (GSM)

WiFi standards

802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax

Transmission speed - 5GHz [Mb/s]

2402

Transmission speed - 2.4GHz [Mb/s]

574

Security

WPA, WPA2, WPA3

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

Type of antenna

Detachable

Detachable antennas

8

RF connectors

(3) RSMA female, (5) SMA female

Integrated 4G/LTE radio part

Yes

Power type

PoE, 4-pin automotive

4G/LTE bands support

(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (28) 700 MHz, (32) 1500 MHz

5G bands support

(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n75) 1500 MHz, (n76) 1500 MHz, (n77) 3700 MHz, (n78) 3500 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

5

LAN speed

(4) 10/100/1000Mbps + (1) 10/100/1000Mbps WAN

Max. power consumption [W]

20

Power via connector/terminal

9 .. 50V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

450

Width [mm]

130

Height [mm]

43

Depth [mm]

103

CPU

ARM Cortex-A53

CPU frequency [MHz]

1300

SIM slot

Yes

SIM slots quantity

2

USB

Yes

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

8 GB

RAM [MB]

1024

Default login and password

admin / (preset password, see label/engraving)

GPS modul

Yes
