Power over Ethernet

9 .. 30V DC

Design

Industry

Max. WAN speed

100M

Operating mode

AP Router, Cellular router

Wireless frequency

2.4 GHz, LTE, GNSS, 5G (GSM)

WiFi standards

802.11n, 802.11b/g

Transmission speed - 2.4GHz [Mb/s]

300

Tx power 2.4GHz [dBm]

20

Security

WPA, WPA2, WPA3, OWE

2.4GHz MIMO

2 x 2

Type of antenna

Detachable

Detachable antennas

5

RF connectors

(3) SMA female, (2) RP-SMA female

Integrated 4G/LTE radio part

Yes

Power type

PoE, 4-pin automotive

4G/LTE bands support

(1) 2100 MHz, (2) 1900 MHz, (3) 1800 MHz, (4) 1700 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (12) 700 MHz, (42) 3500 MHz, (43) 3700 MHz, (17) 700 MHz, (25) 1900 MHz, (26) 850 MHz, (39) 1900 MHz, (28) 700 MHz, (66) 1700 MHz, (71) 600 MHz, (13) 700 MHz, (18) 850 MHz, (19) 850 MHz, (34) 2000 MHz, (14) 700 MHz

5G bands support

(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n79) 4700 MHz, (n66) 1700 MHz, (n71) 600 MHz, (n26) 850 MHz, (n2) 1900 MHz, (n12) 700 MHz, (n13) 700 MHz, (n14) 700 MHz, (n18) 850 MHz, (n25) 1900 MHz, (n30) 2300 MHz, (n48) 3500 MHz, (n70) 2000 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN speed

(4) 10/100Mbps

LAN ports 100M

4

PoE type

PoE-In (only)

Max. power consumption [W]

7

Serial port

RS-232, RS-485

USB ports 2.0

1

Power via connector/terminal

9 .. 30V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

295

Width [mm]

110

Height [mm]

50

Depth [mm]

100

CPU frequency [MHz]

580

SIM slot

Yes

SIM slots quantity

2

USB

Yes

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

32

RAM [MB]

128

Default login and password

admin / (preset password, see label/engraving)

GPS modul

Yes
